JBL JRX215
- Greater efficiency and power handling
- JBL 2414H-C 25 mm (1 in) polymer diaphragm compression driver
- Advanced network topology crossover design
- High-voltage capacitors and inductors
- Progressive Transition™ high frequency waveguide
- Rugged, acoustically superior enclosure
- SonicGuard™ protection
- Durable design
- Dual-angle pole-mount socket
ups.changezipcode ups.edit
Encuentra este producto en Hermes Music Club
Características
Greater efficiency and power handling
JBL 15 in low frequency driver with a 64 mm (2.5 in) diameter edgewound ribbon voice coil provides more cross-sectional wire area in the voice coil gap than round wire designs, for greater efficiency and power handling.
JBL 2414H-C 25 mm (1 in) polymer diaphragm compression driver
Improves high frequency performance as well as system reliability
Advanced network topology crossover design
Shapes frequency response and delivers "coherent summation" in the crossover region
High-voltage capacitors and inductors
High-voltage capacitors and inductors with massive cores and heavy gauge wire enable the crossover network to handle high power without saturating.
Progressive Transition™ high frequency waveguide
Provides superior coverage control, reduced distortion, and smoother frequency response
Rugged, acoustically superior enclosure
The rugged, acoustically superior enclosure is constructed from 19 mm (.75 in) MDF (Medium Density Fiberboard) using advanced adhesives and mechanical fastener technology for extreme durability and improved low-frequency performance.
SonicGuard™ protection
SonicGuard™ protects the high frequency driver from excess power without interrupting the performance.
Durable design
Non-resonant, all-steel handles are used along with an attractive 18-gauge hexagon perforated steel grille to protect components from damage.
Dual-angle pole-mount socket
Allows the speaker to tilt 10° for more uniform audience coverage.
Accesorios
Detalles & Descargas
Item#: JRX215
Affordable, reliable, high quality sound
This trapezoidal, 15" speaker system is at home in live sound, dance music and speech reinforcement. The JRX200 series delivers the performance and prestige JBL is known for at an affordable price point. To meet these conflicting design goals, we looked at every element of the speaker system design. We kept everything that makes a speaker perform and sound its best and we eliminated things that don't. With performance, value and popular price points, we are going to be building a lot of JRX200 speakers. This means we can apply efficient, high-volume production methods and purchase materials at the lowest cost. That's how JRX200 delivers unprecedented value.
Características generales
- Rango de frecuencia Hz (-10 dB)
- 41 - 18,000
- Respuesta de frecuencia Hz (±3 dB)
- 59 - 13,000
- SPL máximo (dB pico)
- 129
- Impedancia nominal (ohmios)
- 8
- Potencia nominal (W, continua)
- 250
- Potencia nominal (W, pico)
- 1000
- Sensitivity (dB SPL 1w/1m)
- 99
Medidas
- Profundidad (pulg)
- 17.0
- Profundidad (mm)
- 432.0
- Altura (en)
- 27.5
- Altura (mm)
- 699.0
- Peso (kg)
- 27.4
- Peso (libras)
- 60.5
- Anchura (en)
- 18.1
- Ancho (mm)
- 460.0
Características
- Dual-angle pole-mount socket
- Sí
- SonicGuard™
- Sí
- 1 x JRX215
